In the building material production process, the high hardness of sand and gravel aggregates causes rapid equipment wear, cement powders tend to generate dust that affects the environment, liquid admixtures require small additions but high precision, and multi-variety production demands frequent recipe changes. These factors collectively constrain production line efficiency and product quality stability. Sihyde Building Material Batching System provides a modular automatic batching solution tailored to the above industry characteristics: the system adopts wear-resistant belt metering for sand and gravel aggregates, sealed screw conveying plus precision weighing for cement powders, and high-precision metering pumps for liquid admixtures. Through an intelligent control system, it enables multi-bin coordination and rapid recipe switching, with fully automated operation, helping enterprises reduce labor costs and stabilize product performance.
Aggregate Metering & Conveying Module
l Wear-Resistant Conveying Method: In response to the high hardness and strong abrasiveness of sand and gravel aggregates, the building material batching system adopts wear-resistant metering belts for conveying, reducing equipment wear and extending service life.
l Metering Accuracy Guarantee: Through belt metering conveying, the system achieves a stable overall weighing accuracy of ±0.5%, ensuring accurate aggregate proportioning, thereby guaranteeing the strength and durability of building material products.
l Production Capacity Adaptability: The system can be customized according to production line requirements, supporting up to 50,000 tons/year of large-scale production, meeting the batch production needs of enterprises of different scales.
Powder Metering & Conveying Module
l Sealed Conveying Structure: For dusty powders such as cement and gypsum, the building material batching system uses sealed screw conveyors to effectively control dust emission and improve the workshop working environment.
l Precision Weighing Method: Through the coordination of screw conveying and weighing devices, the system achieves precise powder weighing, with an overall weighing accuracy of ±0.5%, ensuring consistency in each batch's powder addition.
l Material Applicability: This module is suitable for common building material powders such as cement and gypsum, and can adapt to the production needs of different products like new wall materials and insulation materials.
Liquid Admixture Metering & Dosing Module
l High-Precision Dosing Method: For liquid components like admixtures which require very small additions, the building material batching system adopts high-precision metering pumps to ensure accurate injection according to the recipe.
l Weighing Accuracy Coordination: Liquid dosing and solid weighing are uniformly controlled by the system, with an overall proportioning accuracy stable at ±0.5%, guaranteeing accurate solid-liquid material ratios and avoiding product performance issues caused by admixture deviations.
l Applicable Material Range: This module is compatible with water, admixtures, and other common liquid raw materials in building material production, meeting the batching needs for various products such as terrazzo, aerated concrete, and gypsum boards.
Intelligent Control System
l Multi-Bin Coordinated Operation: Through the intelligent control system, the building material batching system achieves coordinated batching among multiple bins (aggregate bins, powder bins, liquid tanks), with parallel operation of all sections to improve overall efficiency.
l Rapid Recipe Switching: The system supports rapid recipe switching functions, allowing operators to adjust recipes with one click according to different building material products (e.g., blocks, panels, insulation materials), adapting to flexible production modes with multiple varieties and small batches.
l Environmental Treatment Integration: The system design considers coordinated dust and wastewater treatment, and can be linked with dust collectors and wastewater collection devices, meeting environmental requirements of the building material industry and reducing production's environmental impact.
Sihyde Building Material Batching System is closely focused on the practical needs of the building material industry in terms of material diversity, accuracy stability, production continuity, and environmental compliance. With wear-resistant belt conveying, sealed screw weighing, high-precision metering pump dosing, and intelligent control technology, the system effectively solves common pain points such as aggregate abrasion on equipment, powder dust, inaccurate micro-liquid addition, and cumbersome recipe switching. Ultimately, it helps customers achieve stable product quality, reduced labor costs, and enhanced production line flexibility, making it a reliable choice for building material enterprises pursuing automated upgrading.
