In industries such as refractories, building materials, chemicals, and food processing, the batching process has long been plagued by persistent pain points: manual weighing errors, incorrect or missed material feeding, complex operations, long learning curves for new staff, batch scrap caused by misoperations, and difficult quality traceability... With years of deep expertise in batching automation, Qingdao Sihyde has developed a truly user-friendly, reliable, and error-reducing automatic batching line through its ultra-simple operation + full-process error prevention design, helping customers minimize human errors, improve production efficiency, and stabilize product quality.
1. Ultra-Simple Operation: Lower Entry Barriers, Shorten Training Cycles
Sihyde's batching line encapsulates complex automation logic in the background, allowing frontline staff to achieve efficient and stable operation with simple selection and confirmation:
One-Click Start, Fully Automatic Process
Powered by a Siemens PLC + industrial-grade high-definition touchscreen intelligent control system, the line can store hundreds of recipes in advance. Operators simply select the recipe, enter batch information, and click start on the touchscreen. The system then automatically executes the entire process according to preset logic: silo batching, sequential feeding, dual-speed weighing, cart scheduling, and mixing/conveying, eliminating the need for manual valve switching or memorizing complex parameters.
Visual Interface, Intuitive and Easy to Understand
The interface features large icons and full Chinese/English prompts, with real-time display of operating status. Conditions for silos, weighing units, conveyors, and mixers are clearly visible. In the event of common faults, the system automatically pops up error codes and troubleshooting guides, enabling operators to quickly resolve typical issues such as material shortages or unpositioned valves, reducing downtime from simple faults.
Permission-Based Hierarchy, Standardized Operations
A three-tier permission system (Operator / Team Leader / Administrator) is implemented: ordinary operators can only start, view, and record data; team leaders can fine-tune parameters; administrators manage recipe modifications, permission assignments, and data exports. This prevents unauthorized personnel from mistakenly altering recipes or critical parameters.
Manual/Auto Switching with Safety Interlocks
Supports three operating modes: fully automatic, semi-automatic, and manual, to accommodate equipment commissioning or small-batch trial production. Mode switching requires permission confirmation and compliance with safety conditions (e.g., equipment stopped, emergency stop reset) to avoid accidental actions. New staff can perform routine automatic operations independently after half a day of training, while complex anomaly handling remains under supervision.
2. Full-Process Error Prevention: Minimize Risks at the Source with Multi-Layer Protection
Targeting the four error-prone stages—feeding, weighing, sequencing, and cross-contamination—Sihyde integrates multiple poka-yoke (mistake-proofing) and intelligent verification mechanisms to significantly reduce risks of wrong feeding, missed feeding, overweight/underweight, and incorrect batching sequences:
Feeding Error Prevention: QR Code + Indicator Light + Locked Portals, Physically Blocking Misfeeds
For manual bulk bag/ small bag feeding scenarios, each silo is equipped with a material barcode, indicator light, and electronic lock. Before feeding, scanning the barcode identifies the material, and the system automatically verifies consistency with the recipe: if matching, the green light turns on and the feed port unlocks; if mismatched, the red light turns on, the feed port locks, and an audible/visual alarm triggers, physically preventing incorrect feeding. Batch traceability is supported, with records kept for every bag of raw material and every feeding operation for quick issue localization.
Weighing Error Prevention: Dual-Speed Feeding + Tolerance Check + Over/Under Alarm, Ensuring Batching Accuracy
Adopts a coarse/fine dual-speed feeding mode, automatically switching to fine feeding when approaching the target weight. Combined with high-precision weighing modules, dynamic batching accuracy reaches ±0.5%~±1% under typical conditions (free-flowing powders/granules). The system continuously compares actual weight against recipe tolerances, triggering an immediate pop-up + audible/visual alarm for over/underweight conditions, pausing batching and forcing review to prevent recipe failure due to weight deviations.
Process Poka-Yoke: Sequence Locking + Double Confirmation, Preventing Skipped Steps
Batching sequences, silo switching, and valve operations are strictly locked by system logic, preventing progression to the next step without following the standard process. Critical operations (recipe modification, batch start, silo cleaning) require double confirmation before execution. Real-time monitoring of material levels, blockages, and shortages provides early anomaly warnings, avoiding chain reactions from idling or blockages.
Physical Anti-Contamination + Data Traceability, Reducing Cross-Contamination Risks
Silos, conveying lines, and weighing hoppers feature dedicated channels + quick-clean designs, allowing rapid removal of residual material via manual or air blow cleaning during changeovers. Physical isolation of different materials effectively reduces cross-contamination risks. The system automatically records batch data including recipe, weight, time, operator, and equipment status, with data exportable to support compliance with industry traceability requirements.
3. Why Choose Sihyde: Simplicity + Error Prevention, Delivering Tangible Production Value
Cost & Efficiency Improvement: Based on proven solutions, batching labor can be reduced by 20%~50% (depending on the original manual workflow), significantly cutting batch scrap and rework losses caused by misoperations.
Reliability & Durability: Modular design with key components from leading brands. IP65-rated equipment is available, operating within a temperature range of -10℃~50℃, suitable for most industrial dust environments. Custom high-temperature solutions are available for extreme conditions.
Flexible Adaptability: Supports powder, granule, and liquid batching, with customizable multi-silo, multi-recipe, and multi-capacity configurations to meet production needs across refractories, building materials, chemicals, food, and other industries.
